UCC2581D دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
UCC2581D
|
|
حجم فایل
|
110.427
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Boost;Flyback;Forward
-
Datasheet:
Texas Instruments UCC2581D
-
Duty Cycle:
84%
-
Supply Voltage:
6.8V~15V
-
Switching Frequency:
100kHz
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Package:
SOP-14
-
Manufacturer:
Texas Instruments
-
Function:
Step-Up, Step-Up/Step-Down
-
Packaging:
Tube
-
Series:
-
-
Supplier Device Package:
14-SOIC
-
Serial Interfaces:
-
-
Control Features:
Current Limit, Enable, Frequency Control, Soft Start
-
Part Status:
Active
-
Base Part Number:
UCC258
-
Synchronous Rectifier:
No
-
Clock Sync:
Yes
-
Duty Cycle (Max):
84%
-
Output Configuration:
Positive, Isolation Capable
-
Mounting Type:
Surface Mount
-
Number of Outputs:
1
-
Output Phases:
1
-
Output Type:
Transistor Driver
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Voltage - Supply (Vcc/Vdd):
6.8V ~ 15V
-
Frequency - Switching:
Up to 100kHz
-
detail:
Boost, Flyback, Forward Converter Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 14-SOIC
