TM4C129x Silicon Errata دیتاشیت

TM4C129x Silicon Errata

مشخصات دیتاشیت

نام دیتاشیت TM4C129x Silicon Errata
حجم فایل 422.202 کیلوبایت
نوع فایل pdf
تعداد صفحات 117

دانلود دیتاشیت TM4C129x Silicon Errata

دانلود دیتاشیت

سایر مستندات

TM4C129CNCZAD 1772 pages

TI TM4C129CNCZADI3R 1775 pages

مشخصات فنی

  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM-MSeries
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: -
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: Texas Instruments TM4C129CNCZADT3
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 120MHz
  • GPIO Ports Number: 140
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: DMA;PWM
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 1MB
  • Universal Serial Bus: Yes
  • communication protocol: -
  • Operating Voltage Range: 2.97V~3.63V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: BGA-212
  • Manufacturer: Texas Instruments
  • Speed: 120MHz
  • Packaging: Tray
  • Series: Tiva™ C
  • EEPROM Size: 6K x 8
  • Supplier Device Package: 212-NFBGA (10x10)
  • Package / Case: 212-VFBGA
  • Part Status: Active
  • Base Part Number: TM4C
  • Core Size: 32-Bit
  • Data Converters: A/D 24x12b
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, QEI, SPI, SSI, UART/USART, USB OTG
  • Mounting Type: Surface Mount
  • Peripherals: Brown-out Detect/Reset, DMA, Motion Control PWM, POR, PWM, WDT
  • Number of I/O: 140
  • Program Memory Size: 1MB (1M x 8)
  • Core Processor: ARM® Cortex®-M4F
  • Oscillator Type: Internal
  • Voltage - Supply (Vcc/Vdd): 2.97V ~ 3.63V
  • detail: ARM® Cortex®-M4F Tiva™ C Microcontroller IC 32-Bit 120MHz 1MB (1M x 8) FLASH 212-NFBGA (10x10)
