دیتاشیت LMS1587CT-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LMS1585A, LMS1587 |
|---|---|
| حجم فایل | 1793.155 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 14 |
دانلود دیتاشیت LMS1585A, LMS1587 |
LMS1585A, LMS1587 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LMS1587CT-ADJ/NOPB
- Output Type: Adjustable
- Output Current: 3A
- Output Voltage: 1.25V~11.7V
- Dropout Voltage: 1.3V@(3A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 13V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 7mA
- Power Supply Rejection Ratio (PSRR): 72dB@(120Hz)
- Package: TO-220
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 1.3V @ 3A
- Current - Supply (Max): 13mA
- Current - Output: 3A
- Current - Quiescent (Iq): 7mA
- Voltage - Input (Max): 13V
- Base Part Number: LMS1587
- Package / Case: TO-220-3
- Voltage - Output (Max): 11.7V
- Output Configuration: Positive
- Series: -
- Supplier Device Package: TO-220-3
- PSRR: 72dB (120Hz)
- Part Status: Not For New Designs
- Mounting Type: Through Hole
- Control Features: -
- Protection Features: Over Current, Over Temperature
- Voltage - Output (Min/Fixed): 1.25V
- Number of Regulators: 1
- Packaging: Tube
- detail: Linear Voltage Regulator IC 1 Output 3A TO-220-3
