LP2960IM-5.0/NOPB دیتاشیت

LP2960IM-5.0/NOPB

مشخصات دیتاشیت

نام دیتاشیت LP2960IM-5.0/NOPB
حجم فایل 86.195 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت LP2960IM-5.0/NOPB

دانلود دیتاشیت

سایر مستندات

LP2960 22 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP2960IM-5.0/NOPB
  • Package: SOP-16
  • Manufacturer: Texas Instruments
  • Control Features: Enable
  • Base Part Number: LP2960
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Current - Supply (Max): 40mA
  • Part Status: Obsolete
  • Current - Output: 500mA
  • PSRR: -
  • Series: -
  • Voltage - Output (Min/Fixed): 5V
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 600µA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 0.8V @ 500mA
  • Operating Temperature: -40°C ~ 125°C
  • Supplier Device Package: 16-SOIC
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Voltage - Input (Max): 30V
  • Output Type: Fixed
  • Packaging: Tube
  • Voltage - Output (Max): -
  • detail: Linear Voltage Regulator IC 1 Output 500mA 16-SOIC
