CSD18510Q5B Datasheet دیتاشیت

CSD18510Q5B Datasheet

مشخصات دیتاشیت

نام دیتاشیت CSD18510Q5B Datasheet
حجم فایل 607.417 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت CSD18510Q5B Datasheet

دانلود دیتاشیت

سایر مستندات

CSD18510Q5BT 17 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Texas Instruments CSD18510Q5BT
  • Package: VSON-CLIP-8(6x5)
  • Manufacturer: Texas Instruments
  • Power Dissipation (Max): 156W (Tc)
  • Base Part Number: CSD1851
  • Gate Charge (Qg) (Max) @ Vgs: 153nC @ 10V
  • FET Feature: -
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Series: NexFET™
  • Current - Continuous Drain (Id) @ 25°C: 300A (Tc)
  • Supplier Device Package: 8-VSON-CLIP (5x6)
  • Vgs (Max): ±20V
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Package / Case: 8-PowerTDFN
  • Drain to Source Voltage (Vdss): 40V
  • Rds On (Max) @ Id, Vgs: 0.96mOhm @ 32A, 10V
  • Input Capacitance (Ciss) (Max) @ Vds: 11400pF @ 20V
  • Packaging: Cut Tape (CT)
  • Vgs(th) (Max) @ Id: 2.3V @ 250µA
  • Mounting Type: Surface Mount
  • Technology: MOSFET (Metal Oxide)
  • Part Status: Active
  • FET Type: N-Channel
  • detail: N-Channel 40V 300A (Tc) 156W (Tc) Surface Mount 8-VSON-CLIP (5x6)
