TPS2549 Datasheet دیتاشیت

TPS2549 Datasheet

مشخصات دیتاشیت

نام دیتاشیت TPS2549 Datasheet
حجم فایل 1980.078 کیلوبایت
نوع فایل pdf
تعداد صفحات 44

مشاهده دیتاشیت TPS2549 Datasheet

دانلود دیتاشیت

سایر مستندات

TPS2549RTET 43 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS2549RTET
  • Input Voltage: 4.5V~6.5V
  • Output Current: 3A
  • Number of Outputs: 1
  • Resistor On-State: 47mΩ
  • Operating Temperature -: -40°C~+125°C
  • Package: QFN-16-EP(3x3)
  • Manufacturer: Texas Instruments
  • Input Type: Non-Inverting
  • Fault Protection: Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO
  • Interface: On/Off
  • Features: Load Discharge, Status Flag
  • Series: -
  • Current - Output (Max): 3A
  • Package / Case: 16-WFQFN Exposed Pad
  • Packaging: Cut Tape (CT)
  • Ratio - Input:Output: 1:1
  • Part Status: Active
  • Rds On (Typ): 47mOhm
  • Base Part Number: TPS254
  • Output Type: N-Channel
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Voltage - Load: 4.5V ~ 6.5V
  • Output Configuration: High Side
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-WQFN (3x3)
  • Switch Type: USB Switch
  • Voltage - Supply (Vcc/Vdd): Not Required
  • detail: Power Switch/Driver 1:1 N-Channel 3A 16-WQFN (3x3)
