74AC11008D دیتاشیت

74AC11008D

مشخصات دیتاشیت

نام دیتاشیت 74AC11008D
حجم فایل 56.969 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

مشاهده دیتاشیت 74AC11008D

دانلود دیتاشیت

سایر مستندات

74AC11008 15 pages

74AC11008D 14 pages

74AC11008D 14 pages

مشخصات فنی

  • RoHS: true
  • Series: 74AC
  • Category: Logic ICs/Gates
  • Datasheet: Texas Instruments 74AC11008D
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 3V~5.5V
  • Logic Gate Type: And
  • Number of Channels: 4
  • Low Level Range (VIL): 0.9V~1.65V
  • Operating Temperature: -40°C~+85°C
  • High Level Range (VIH): 2.1V~3.85V
  • Propagation Delay Time: 6.2ns@5V,50pF
  • Quiescent Current (Max): 4uA
  • Package: SOP-16
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 3V ~ 5.5V
  • Logic Level - Low: 0.9V ~ 1.65V
  • Number of Circuits: 4
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Max Propagation Delay @ V, Max CL: 6.2ns @ 5V, 50pF
  • Number of Inputs: 2
  • Base Part Number: 74AC11
  • Mounting Type: Surface Mount
  • Current - Quiescent (Max): 4µA
  • Supplier Device Package: 16-SOIC
  • Logic Type: AND Gate
  • Packaging: Tube
  • Features: -
  • Current - Output High, Low: 24mA, 24mA
  • Part Status: Active
  • Logic Level - High: 2.1V ~ 3.85V
  • detail: AND Gate IC 4 Channel 16-SOIC
