- دیتاشیت LM339J
LM339J دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LM339J |
|---|---|
| حجم فایل | 101.546 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LM339J |
دانلود دیتاشیت |
|---|
سایر مستندات
Signal e-Book: OP Amp Design Topics 37 pages
LM139/239/339/2901/3302 32 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments LM339J
- Output Type: 开集;轨到轨
- Supply Voltage: 2V~30V;1V~15V
- Number of Elements: -
- Operating Temperature: 0°C~+70°C
- Input Bias Current (Ib): 0.25uA
- Input Offset Voltage (Vos): 3mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): -
- Package: DIP-16
- Manufacturer: Texas Instruments
- Base Part Number: LM339
- Voltage - Input Offset (Max): 3mV @ 30V
- CMRR, PSRR (Typ): -
- Series: -
- Supplier Device Package: 14-CDIP
- Propagation Delay (Max): -
- Hysteresis: -
- Mounting Type: Through Hole
- Type: Differential
- Current - Output (Typ): 20mA
- Package / Case: 14-CDIP (0.300", 7.62mm)
- Part Status: Active
- Packaging: Tube
- Current - Quiescent (Max): 2.5mA
- Current - Input Bias (Max): 0.25µA @ 5V
- Voltage - Supply, Single/Dual (±): 2V ~ 30V, ±1V ~ 15V
- detail: Comparator Differential CMOS, MOS, Open-Collector, TTL 14-CDIP
