دیتاشیت SN74LS642-1N
مشخصات دیتاشیت
نام دیتاشیت | SN54LS640-42/644-45, SN74LS640-42/644-45 |
---|---|
حجم فایل | 1698.81 کیلوبایت |
نوع فایل | |
تعداد صفحات | 25 |
دانلود دیتاشیت SN54LS640-42/644-45, SN74LS640-42/644-45 |
SN54LS640-42/644-45, SN74LS640-42/644-45 Datasheet |
---|
مشخصات
- Voltage - Supply: 4.75V ~ 5.25V
- Output Type: Open Collector
- Input Type: -
- Operating Temperature: 0°C ~ 70°C (TA)
- Package / Case: 20-DIP (0.300", 7.62mm)
- Series: 74LS
- Manufacturer: Texas Instruments
- Base Part Number: SN74LS64
- Supplier Device Package: 20-PDIP
- Mounting Type: Through Hole
- Number of Bits per Element: 8
- Number of Elements: 1
- Logic Type: Transceiver, Inverting
- Packaging: Tube
- Current - Output High, Low: -, 48mA
- Part Status: Active
- detail: Transceiver, Inverting 1 Element 8 Bit per Element Open Collector Output 20-PDIP
