دیتاشیت MSP430FR4132IPMR
مشخصات دیتاشیت
| نام دیتاشیت | MSP430FR4132IPMR |
|---|---|
| حجم فایل | 102.864 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 109 |
MSP430FR4132IPMR |
دانلود دیتاشیت |
|---|
سایر مستندات
MSP430FR4xx, MSP430FR2xx Family User Guide 676 pages
MSP430FR4131-33 Datasheet 102 pages
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: MSP430
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Texas Instruments MSP430FR4132IPMR
- PWM (Bit): -
- LCD Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 16MHz
- GPIO Ports Number: 60
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: LCD/LED Driver
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 8.5KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-64(10x10)
- Manufacturer: Texas Instruments
- Base Part Number: 430FR4132
- Core Size: 16-Bit
- Speed: 16MHz
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C (TA)
- Package / Case: 64-LQFP
- Series: MSP430™ FRAM
- Supplier Device Package: 64-LQFP (10x10)
- Connectivity: I²C, IrDA, SCI, SPI, UART/USART
- EEPROM Size: -
- Data Converters: A/D 10x10b
- Peripherals: Brown-out Detect/Reset, LCD, POR, PWM, WDT
- Number of I/O: 60
- Part Status: Active
- Core Processor: MSP430
- Oscillator Type: Internal
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Program Memory Size: 8.5KB (8.5K x 8)
- detail: MSP430 MSP430™ FRAM Microcontroller IC 16-Bit 16MHz 8.5KB (8.5K x 8) FRAM 64-LQFP (10x10)
