دیتاشیت LM3686TLE-AADW/NOPB

LM3686

مشخصات دیتاشیت

نام دیتاشیت LM3686
حجم فایل 2799.828 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت LM3686

LM3686 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Datasheet: Texas Instruments LM3686TLE-AADW/NOPB
  • Input Voltage: 2.7V~5.5V
  • Number of Outputs: 3
  • Switching Frequency: 3MHz
  • Operating Temperature: -40°C~+85°C
  • Package: BGA-12
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 2.7V ~ 5.5V
  • Base Part Number: LM3686
  • Package / Case: 12-WFBGA
  • Series: -
  • Voltage/Current - Output 3: 2.8V, 300mA
  • w/Supervisor: No
  • Supplier Device Package: 12-µSMD (1.49x2)
  • Mounting Type: Surface Mount
  • Voltage/Current - Output 1: 1.8V, 600mA
  • Topology: Step-Down (Buck) Synchronous (1), Linear (LDO) (2)
  • Packaging: Cut Tape (CT)
  • w/LED Driver: No
  • Voltage/Current - Output 2: 1.2V, 350mA
  • w/Sequencer: No
  • Frequency - Switching: 3MHz
  • Part Status: Active
  • detail: PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 3MHz 12-µSMD (1.49x2)
