LM26LV, LM26LV-Q1 Datasheet 数据手册
数据手册规格
| 数据手册名称 | LM26LV, LM26LV-Q1 Datasheet |
|---|---|
| 文件大小 | 1872.357 千字节 |
| 文件类型 | |
| 页数 | 35 |
下载数据手册 LM26LV, LM26LV-Q1 Datasheet |
下载数据手册 |
|---|
其他文档
LM26LVCISD-080/NOPB 36 pages
技术规格
- RoHS: true
- Category: Sensors/Thermostat Switches
- Datasheet: Texas Instruments LM26LVCISD-085/NOPB
- Package: WSON-6(2.2x2.5)
- Manufacturer: Texas Instruments
- Voltage - Supply: 1.6V ~ 5.5V
- Base Part Number: LM26
- Accuracy: ±2.2°C
- Current - Output (Max): 7mA
- Package / Case: 6-WDFN Exposed Pad
- Series: -
- Current - Supply: 8µA
- Output: Active High, Active Low
- Output Function: OverTemp, /OverTemp, VTemp
- Supplier Device Package: 6-WSON (2.2x2.5)
- Trip Temperature Threshold: Hot
- Selectable Hysteresis: No
- Mounting Type: Surface Mount
- Features: Trip Test
- Output Type: Open Drain, Push-Pull
- Packaging: Cut Tape (CT)
- Switching Temperature: 85°C
- Operating Temperature: -50°C ~ 150°C
- Part Status: Active
- detail: Thermostat 85°C Active High, Active Low Open Drain, Push-Pull 6-WSON (2.2x2.5)
