دیتاشیت LM2770SD-1215/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2770 |
|---|---|
| حجم فایل | 2470.583 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LM2770 |
LM2770 Datasheet |
|---|
مشخصات
- Function: Step-Down
- Voltage - Input (Max): 5.5V
- Frequency - Switching: 700kHz
- Operating Temperature: -30°C ~ 85°C (TA)
- Packaging: Cut Tape (CT)
- Series: -
- Output Configuration: Positive
- Manufacturer: Texas Instruments
- Base Part Number: LM2770
- Supplier Device Package: 10-WSON (3x3)
- Mounting Type: Surface Mount
- Number of Outputs: 1
- Voltage - Output (Max): -
- Synchronous Rectifier: No
- Output Type: Programmable
- Package / Case: 10-WFDFN Exposed Pad
- Topology: Charge Pump
- Voltage - Output (Min/Fixed): 1.2V, 1.5V
- Voltage - Input (Min): 2.7V
- Part Status: Active
- Current - Output: 250mA
- detail: Charge Pump Switching Regulator IC Positive Programmable 1.2V, 1.5V 1 Output 250mA 10-WFDFN Exposed Pad
