TPS2021D Datasheet

TPS2021D

Datasheet specifications

Datasheet's name TPS2021D
File size 119.72 KB
File type pdf
Number of pages 30

Download Datasheet TPS2021D

Download Datasheet

Other documentations

TPS2020 - TPS2024 Datasheet 29 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS2024P
  • Package: PDIP-8
  • Manufacturer: Texas Instruments
  • Input Type: Non-Inverting
  • Fault Protection: Current Limiting (Fixed), Over Temperature, UVLO
  • Interface: On/Off
  • Features: Status Flag
  • Series: -
  • Current - Output (Max): 2A
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • Ratio - Input:Output: 1:1
  • Part Status: Active
  • Rds On (Typ): 33mOhm
  • Base Part Number: TPS202
  • Output Type: N-Channel
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Voltage - Load: 2.7V ~ 5.5V
  • Output Configuration: High Side
  • Mounting Type: Through Hole
  • Number of Outputs: 1
  • Supplier Device Package: 8-PDIP
  • Switch Type: General Purpose
  • Voltage - Supply (Vcc/Vdd): Not Required
  • detail: Power Switch/Driver 1:1 N-Channel 2A 8-PDIP
