LM9071SX/NOPB دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LM9071SX/NOPB
|
|
حجم فایل
|
84.383
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LM9071SX/NOPB
-
Output Current:
250mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.8V@(250mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
26V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
4mA
-
Power Supply Rejection Ratio (PSRR):
60dB@(120Hz)
-
Package:
TO-263-5
-
Manufacturer:
Texas Instruments
-
Control Features:
-
-
Base Part Number:
LM9071
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Current - Supply (Max):
50mA
-
Part Status:
Obsolete
-
Current - Output:
250mA
-
PSRR:
60dB (120Hz)
-
Series:
-
-
Voltage - Output (Min/Fixed):
5V
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
4mA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
0.8V @ 250mA
-
Supplier Device Package:
DDPAK/TO-263-5
-
Protection Features:
Over Temperature, Over Voltage, Reverse Polarity, Short Circuit
-
Voltage - Input (Max):
26V
-
Output Type:
Fixed
-
Packaging:
Tape & Reel (TR)
-
Voltage - Output (Max):
-
-
detail:
Linear Voltage Regulator IC 1 Output 250mA DDPAK/TO-263-5
