دیتاشیت LMZ34002EVM-001

مشخصات دیتاشیت

دانلود دیتاشیت LNZ34002EVM-001 User Guide	LNZ34002EVM-001 User Guide Datasheet

Regulator Topology: Inverting
Base Part Number: LMZ3400
Outputs and Type: 1, Non-Isolated
Series: SIMPLE SWITCHER®
Board Type: Fully Populated
Manufacturer: Texas Instruments
Utilized IC / Part: LMZ34002
Voltage - Input: 4.5V ~ 40V
Main Purpose: DC/DC, Negative Inverter
Voltage - Output: -3.3V, -5V, -12V, -15V
Supplied Contents: Board(s)
Frequency - Switching: 800kHz
Part Status: Active
Current - Output: 2A
detail: LMZ34002 SIMPLE SWITCHER® DC/DC, Negative Inverter 1, Non-Isolated Outputs Evaluation Board
