ADS7800 Datasheet

ADS7800

Datasheet specifications

Datasheet's name ADS7800
File size 899.532 KB
File type pdf
Number of pages 19

Download Datasheet ADS7800

Download Datasheet

Other documentations

ADS7800KU 20 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Texas Instruments ADS7800AH
  • Interface: Parallel
  • resolution: 12Bit
  • Supply Voltage: 5V;11.4V~16.5V
  • number of channels: 1
  • sampling frequency: 333kHz
  • Operating Temperature: -40°C~+85°C
  • Package: CDIP-24
  • Manufacturer: Texas Instruments
  • Input Type: Single Ended
  • Packaging: Tube
  • Series: -
  • Number of A/D Converters: 1
  • Number of Inputs: 1
  • Features: -
  • Ratio - S/H:ADC: 1:1
  • Supplier Device Package: 24-CDIP
  • Data Interface: Parallel
  • Package / Case: 24-CDIP (0.300", 7.62mm)
  • Sampling Rate (Per Second): 333k
  • Configuration: S/H-ADC
  • Part Status: Active
  • Base Part Number: ADS7800
  • Architecture: SAR
  • Reference Type: Internal
  • Mounting Type: Through Hole
  • Number of Bits: 12
  • Voltage - Supply, Analog: 5V, -11.4V ~ 16.5V
  • Voltage - Supply, Digital: 5V
  • detail: 12 Bit Analog to Digital Converter 1 Input 1 SAR 24-CDIP
