دیتاشیت TPS65261-1RHBR
مشخصات دیتاشیت
| نام دیتاشیت | TPS65261,TPS65261-1 |
|---|---|
| حجم فایل | 2369.192 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت TPS65261,TPS65261-1 |
TPS65261,TPS65261-1 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS65261-1RHBR
- Output Type: Adjustable
- Input Voltage: 4.5V~18V
- Output Voltage: 0.6V~18V
- Number of Outputs: 3
- Switching Frequency: 2MHz
- Output Current (Max): 3A;2A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: QFN-32-EP(5x5)
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 18V
- Frequency - Switching: 250kHz ~ 2MHz
- Packaging: Cut Tape (CT)
- Series: -
- Output Configuration: Positive
- Base Part Number: TPS652
- Supplier Device Package: 32-VQFN (5x5)
- Mounting Type: Surface Mount
- Voltage - Output (Max): 18V
- Synchronous Rectifier: Yes
- Package / Case: 32-VFQFN Exposed Pad
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Input (Min): 4.5V
- Part Status: Active
- Current - Output: 3A, 2A
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 3 Output 3A, 2A 32-VFQFN Exposed Pad
