دیتاشیت ESD351DPYR

ESD351

مشخصات دیتاشیت

نام دیتاشیت ESD351
حجم فایل 903.674 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت ESD351

ESD351 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments ESD351DPYR
  • Clamping Voltage@Ipp: 6.5V
  • Operating Temperature: -40°C~+125°C
  • Breakdown Voltage (VBR): 4.5V
  • Peak Pulse Power(Ppp)@8/20us: 36W
  • Junction Capacitance(Cj)@1MHz: 1.8pF@1MHz
  • Peak Pulse Current(Ipp)@8/20us: 16A
  • Reverse Stand-Off Voltage (Vrwm): 3.6V
  • Package: X1-SON-2(0.6x1)
  • Manufacturer: Texas Instruments
  • Base Part Number: ESD351
  • Voltage - Clamping (Max) @ Ipp: 6.5V
  • Power Line Protection: No
  • Package / Case: 0402 (1006 Metric)
  • Series: -
  • Capacitance @ Frequency: 1.8pF @ 1MHz
  • Applications: General Purpose
  • Power - Peak Pulse: 36W
  • Mounting Type: Surface Mount
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 3.6V
  • Supplier Device Package: 2-X1SON (1x.60)
  • Packaging: Cut Tape (CT)
  • Current - Peak Pulse (10/1000µs): 16A
  • Unidirectional Channels: 1
  • Part Status: Active
  • Voltage - Breakdown (Min): 4.5V
  • detail: 6.5V Clamp 16A Ipp Tvs Diode Surface Mount 2-X1SON (1x.60)
