TPS61163AYFFR 数据手册
其他文档
TPS6116xA 35 pages
技术规格
- RoHS: true
- Type: DC-DCVoltage Stabilizer
- Dimming: Analog;PWM
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 2
- Topology: boost converter
- Datasheet: Texas Instruments TPS61163AYFFR
- Input Voltage: 2.7V~6.5V
- Output Current: 30mA
- Output Voltage: 2.7V~38V
- Switch Frequency: 1.2MHz
- Operating temperature: -40°C~+85°C
- Package: BGA-9
- Manufacturer: Texas Instruments
- Base Part Number: TPS611
- Frequency: 1.2MHz
- Voltage - Supply (Min): 2.7V
- Series: -
- Applications: Backlight
- Internal Switch(s): Yes
- Supplier Device Package: 9-DSBGA
- Current - Output / Channel: 30mA
- Mounting Type: Surface Mount
- Number of Outputs: 2
- Voltage - Output: 2.7V ~ 38V
- Voltage - Supply (Max): 6.5V
- Packaging: Cut Tape (CT)
- Package / Case: 9-UFBGA, DSBGA
- Part Status: Active
- detail: LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 30mA 9-DSBGA
