دیتاشیت CD74HC157M96

CD54/74HC(T)157/158

مشخصات دیتاشیت

نام دیتاشیت CD54/74HC(T)157/158
حجم فایل 492.572 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت CD54/74HC(T)157/158

CD54/74HC(T)157/158 Datasheet

مشخصات

  • RoHS: true
  • Type: Multiplexers
  • Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
  • Datasheet: Texas Instruments CD74HC157M96
  • Sink Current: 5.2mA
  • Source Current: 5.2mA
  • Supply Voltage: 2V~6V
  • Operating temperature: -55°C~+125°C
  • Voltage Supply Source: Single supply
  • Package: SOP-16
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 2V ~ 6V
  • Base Part Number: 74HC157
  • Circuit: 4 x 2:1
  • Series: 74HC
  • Current - Output High, Low: 5.2mA, 5.2mA
  • Independent Circuits: 1
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-SOIC
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • detail: Multiplexer 4 x 2:1 16-SOIC
