UCC28704DBVT-1 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | UCC28704DBVT-1 |
|---|---|
| حجم فایل | 100.713 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت UCC28704DBVT-1 |
دانلود دیتاشیت |
|---|
سایر مستندات
UCC28704 Datasheet 45 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Flyback
- Datasheet: Texas Instruments UCC28704DBVT-1
- Supply Voltage: 8.5V~35V
- Output Isolation: Isolation
- Switching Frequency: 85kHz
- Operating Temperature: -40°C~+125°C@(Tj)
- Package: SOT-23-6
- Manufacturer: Texas Instruments
- Base Part Number: UCC287
- Mounting Type: Surface Mount
- Series: -
- Duty Cycle: -
- Internal Switch(s): No
- Supplier Device Package: SOT-23-6
- Voltage - Breakdown: -
- Voltage - Start Up: 21V
- Packaging: Cut Tape (CT)
- Package / Case: SOT-23-6
- Control Features: -
- Voltage - Supply (Vcc/Vdd): 8.5V ~ 35V
- Frequency - Switching: 85kHz
- Part Status: Active
- Fault Protection: Current Limiting, Over Temperature, Over Voltage, Short Circuit
- detail: Converter Offline Flyback Topology 85kHz SOT-23-6
