دیتاشیت UC3842ADTR

UC3842ADTR

مشخصات دیتاشیت

نام دیتاشیت UC3842ADTR
حجم فایل 92.931 کیلوبایت
نوع فایل pdf
تعداد صفحات 54

UC3842ADTR

دانلود دیتاشیت

سایر مستندات

UC1842A-45A, UC2842A-45A, UC3842A-45A 50 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Datasheet: Texas Instruments UC3842ADTR
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Function: Step-Up, Step-Down, Step-Up/Step-Down
  • Packaging: Cut Tape (CT)
  • Series: -
  • Supplier Device Package: 14-SOIC
  • Serial Interfaces: -
  • Topology: Boost, Buck, Buck-Boost, Flyback, Forward
  • Control Features: Frequency Control
  • Part Status: Active
  • Base Part Number: UC384
  • Synchronous Rectifier: No
  • Clock Sync: No
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Duty Cycle (Max): 96%
  • Output Configuration: Positive
  • Mounting Type: Surface Mount
  • Number of Outputs: 1
  • Output Phases: 1
  • Output Type: Transistor Driver
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Voltage - Supply (Vcc/Vdd): 10V ~ 30V
  • Frequency - Switching: Up to 500kHz
  • detail: Boost, Buck, Buck-Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 14-SOIC
