- دیتاشیت TPD5E003DPFR
TPD5E003DPFR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPD5E003DPFR |
|---|---|
| حجم فایل | 63.751 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت TPD5E003DPFR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPD5E003 Datasheet 17 pages
TPD5E003DPFR 3 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: Texas Instruments TPD5E003DPFR
- Clamping Voltage@Ipp: 19.5V
- Operating Temperature: -40°C~+125°C@(Ta)
- Breakdown Voltage (VBR): 6V
- Peak Pulse Power(Ppp)@8/20us: 40W
- Junction Capacitance(Cj)@1MHz: 10pF@1MHz
- Peak Pulse Current(Ipp)@8/20us: 3A@(8/20us)
- Reverse Stand-Off Voltage (Vrwm): 5V
- Package: X2-SON-6(1x1)
- Manufacturer: Texas Instruments
- Base Part Number: TPD5E0
- Bidirectional Channels: 4
- Voltage - Clamping (Max) @ Ipp: 19.5V
- Power Line Protection: No
- Package / Case: 6-XFDFN
- Series: -
- Capacitance @ Frequency: 10pF @ 1MHz
- Applications: General Purpose
- Power - Peak Pulse: 40W
- Mounting Type: Surface Mount
- Type: Zener
- Voltage - Reverse Standoff (Typ): 5V (Max)
- Supplier Device Package: 6-X2SON (1x1)
- Packaging: Cut Tape (CT)
- Current - Peak Pulse (10/1000µs): 3A (8/20µs)
- Unidirectional Channels: 5
- Part Status: Active
- Voltage - Breakdown (Min): 6V
- detail: 19.5V Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount 6-X2SON (1x1)
