دیتاشیت TMUX1204DQAR

مشخصات دیتاشیت

دانلود دیتاشیت TMUX1204 Datasheet	TMUX1204 Datasheet Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TMUX1204DQAR
Switch Circuit: -
Package: DFN-10(1x2.5)
Manufacturer: Texas Instruments
Base Part Number: TMUX12
Current - Leakage (IS(off)) (Max): 75nA (Typ)
Number of Circuits: 1
Voltage - Supply, Dual (V±): -
Series: -
-3db Bandwidth: 125MHz
Charge Injection: 9pC
Switch Time (Ton, Toff) (Max): 14ns, 5ns (Typ)
Supplier Device Package: 10-USON (2.5x1)
Channel-to-Channel Matching (ΔRon): 150mOhm
Operating Temperature: -40°C ~ 125°C (TA)
Channel Capacitance (CS(off), CD(off)): 13pF, 38pF
Voltage - Supply, Single (V+): 1.08V ~ 5.5V
Package / Case: 10-UFDFN
On-State Resistance (Max): 5Ohm (Typ)
Packaging: Cut Tape (CT)
Crosstalk: -42dB @ 10MHz
Multiplexer/Demultiplexer Circuit: 4:1
Part Status: Active
detail: 1 Circuit IC Switch 4:1 5Ohm (Typ) 10-USON (2.5x1)
