دیتاشیت SN74LS245DBR

مشخصات دیتاشیت

دانلود دیتاشیت SN54LS245, SN74LS245	SN54LS245, SN74LS245 Datasheet

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74LS245DBR
Input type: -
output type: Tri-State
Logic Family: 74LS
Sink Current: 24mA
Source Current: 15mA
Supply Voltage: 4.75V~5.25V
Number of Elements: 1
Operating Temperature: 0°C~+70°C
Number of Bits per Element: 8
Package: SSOP-20
Manufacturer: Texas Instruments
Voltage - Supply: 4.75V ~ 5.25V
Package / Case: 20-SSOP (0.209", 5.30mm Width)
Series: 74LS
Base Part Number: SN74LS24
Supplier Device Package: 20-SSOP
Mounting Type: Surface Mount
Logic Type: Transceiver, Non-Inverting
Packaging: Cut Tape (CT)
Current - Output High, Low: 15mA, 24mA
Part Status: Active
detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output 20-SSOP
