- دیتاشیت SN74LVCHR16245ALR
SN74LVCHR16245ALR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVCHR16245ALR |
|---|---|
| حجم فایل | 85.253 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت SN74LVCHR16245ALR |
دانلود دیتاشیت |
|---|
سایر مستندات
Logic Guide 20 pages
Signal Switch Data Book 1267 pages
Digital Logic Data Book 794 pages
LVC & LV Data Book 915 pages
SN74LVCHR16245A Datasheet 28 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LVCHR16245ALR
- output type: Tri-State
- Logic Family: 74LVCHR
- Sink Current: 12mA
- Source Current: 12mA
- Supply Voltage: 1.65V~3.6V
- Number of Elements: 2
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 8
- Package: SSOP-48-300mil
- Manufacturer: Texas Instruments
- Voltage - Supply: 1.65V ~ 3.6V
- Input Type: -
- Package / Case: 48-BSSOP (0.295", 7.50mm Width)
- Series: 74LVCHR
- Base Part Number: SN74LVCHR
- Supplier Device Package: 48-SSOP
- Mounting Type: Surface Mount
- Logic Type: Transceiver, Non-Inverting
- Packaging: Cut Tape (CT)
- Current - Output High, Low: 12mA, 12mA
- Part Status: Active
- detail: Transceiver, Non-Inverting 2 Element 8 Bit per Element 3-State Output 48-SSOP
