دیتاشیت LM2937ESX-8.0/NOPB

LM2937

مشخصات دیتاشیت

نام دیتاشیت LM2937
حجم فایل 2032.275 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت LM2937

LM2937 Datasheet

مشخصات

  • Control Features: -
  • Base Part Number: LM2937
  • Package / Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
  • Current - Supply (Max): 20mA
  • Part Status: Obsolete
  • Current - Output: 500mA
  • PSRR: -
  • Series: -
  • Voltage - Output (Min/Fixed): 8V
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 2mA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 1V @ 50mA
  • Operating Temperature: -40°C ~ 125°C
  • Supplier Device Package: DDPAK/TO-263-3
  • Protection Features: Over Temperature, Reverse Polarity, Short Circuit
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 26V
  • Output Type: Fixed
  • Packaging: Tape & Reel (TR)
  • Voltage - Output (Max): -
  • detail: Linear Voltage Regulator IC 1 Output 500mA DDPAK/TO-263-3
