CD74HC4351E دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | CD74HC4351E |
|---|---|
| حجم فایل | 484.894 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت CD74HC4351E |
دانلود دیتاشیت |
|---|
سایر مستندات
CD54,74HC(T)4351,52 25 pages
CD74HC4352E 26 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments CD74HC4351E
- Turn-on time: 55ns
- Turn-off time: 50ns
- Supply Voltage: 2V~6V
- Switch Circuit: -
- Number of Channels: 1
- On-State Resistance (Max): 130Ω
- Package: PDIP-20
- Manufacturer: Texas Instruments
- Current - Leakage (IS(off)) (Max): 200nA
- Number of Circuits: 1
- Package / Case: 20-DIP (0.300", 7.62mm)
- Series: -
- Charge Injection: -
- Packaging: Tube
- Channel Capacitance (CS(off), CD(off)): 5pF, 25pF
- Voltage - Supply, Single (V+): 2V ~ 6V
- Channel-to-Channel Matching (ΔRon): 5Ohm
- Voltage - Supply, Dual (V±): ±1V ~ 5V
- Part Status: Active
- Base Part Number: 74HC4351
- Operating Temperature: -55°C ~ 125°C (TA)
- -3db Bandwidth: 145MHz
- Switch Time (Ton, Toff) (Max): 55ns, 50ns
- Mounting Type: Through Hole
- Supplier Device Package: 20-PDIP
- Crosstalk: -
- Multiplexer/Demultiplexer Circuit: 8:1
- detail: 1 Circuit IC Switch 8:1 130Ohm 20-PDIP
