LM5033MM/NOPB دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LM5033MM/NOPB	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Buck-boost type
Topology: Full-Bridge;Half-Bridge;Push-pull
Datasheet: Texas Instruments LM5033MM/NOPB
Input Voltage: 15V~90V
Duty Cycle (Max): -
Number of Outputs: 2
Switching Frequency: 200kHz;600kHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-10
Manufacturer: Texas Instruments
Voltage - Supply (Vcc/Vdd): 15V ~ 90V
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Base Part Number: LM5033
Clock Sync: Yes
Control Features: Frequency Control, Soft Start
Part Status: Obsolete
Series: -
Mounting Type: Surface Mount
Output Type: PWM Signal
Output Configuration: Positive
Synchronous Rectifier: Yes
Frequency - Switching: 200kHz, 600kHz
Supplier Device Package: 10-VSSOP
Packaging: Cut Tape (CT)
Output Phases: 1
Serial Interfaces: -
detail: Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 10-VSSOP
