دیتاشیت SN74HC240NSR
مشخصات دیتاشیت
| نام دیتاشیت | SN54HC240, SN74HC240 |
|---|---|
| حجم فایل | 1550.518 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت SN54HC240, SN74HC240 |
SN54HC240, SN74HC240 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Logic ICs/Inverters
- Datasheet: Texas Instruments SN74HC240NSR
- Package: SOP-20
- Manufacturer: Texas Instruments
- Voltage - Supply: 2V ~ 6V
- Output Type: 3-State
- Input Type: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Package / Case: 20-SOIC (0.209", 5.30mm Width)
- Series: 74HC
- Base Part Number: SN74HC2
- Supplier Device Package: 20-SO
- Mounting Type: Surface Mount
- Number of Bits per Element: 4
- Number of Elements: 2
- Logic Type: Buffer, Inverting
- Packaging: Cut Tape (CT)
- Current - Output High, Low: 7.8mA, 7.8mA
- Part Status: Active
- detail: Buffer, Inverting 2 Element 4 Bit per Element 3-State Output 20-SO
