دیتاشیت SN74HC574NSR
مشخصات دیتاشیت
| نام دیتاشیت | SN54HC574, SN74HC574 |
|---|---|
| حجم فایل | 1557.795 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت SN54HC574, SN74HC574 |
SN54HC574, SN74HC574 Datasheet |
|---|
مشخصات
- RoHS: true
- Type: D-Type
- Series: 74HC
- Category: Logic ICs/Flip Flops
- Function: -
- Datasheet: Texas Instruments SN74HC574NSR
- Output Type: Tri-State;Non-Inverted
- Sink Current: 7.8mA
- Trigger Type: 上升沿
- Source Current: 7.8mA
- Supply Voltage: 2V~6V
- Clock Frequency: 40MHz
- Input Capacitance: 3pF
- Quiescent Current (Iq): 8uA
- Maximum Propagation Delay: 31ns@6V,50pF
- Package: SOP-20-208mil
- Manufacturer: Texas Instruments
- Max Propagation Delay @ V, Max CL: 31ns @ 6V, 50pF
- Number of Elements: 1
- Operating Temperature: -40°C ~ 85°C (TA)
- Package / Case: 20-SOIC (0.209", 5.30mm Width)
- Current - Quiescent (Iq): 8µA
- Base Part Number: SN74HC5
- Supplier Device Package: 20-SO
- Number of Bits per Element: 8
- Packaging: Cut Tape (CT)
- Current - Output High, Low: 7.8mA, 7.8mA
- Mounting Type: Surface Mount
- Voltage - Supply: 2V ~ 6V
- Part Status: Active
- detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-SOIC (0.209", 5.30mm Width)
