Power Management Guide Datasheet

Power Management Guide

Datasheet specifications

Datasheet's name Power Management Guide
File size 6420.273 KB
File type pdf
Number of pages 93

Download Datasheet Power Management Guide

Download Datasheet

Other documentations

Connected Sensors Building Automation Systems Guide 13 pages

LP5907 Datasheet 47 pages

LDOs Quick Reference Guide 6 pages

LP5907SNX-2.8/NOPB 46 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP5907SNX-1.9
  • Package: X2-SON-4-EP(1x1)
  • Manufacturer: Texas Instruments
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.25V @ 250mA
  • Operating Temperature: -40°C ~ 125°C
  • Output Configuration: Positive
  • Series: -
  • Current - Quiescent (Iq): 25µA
  • Base Part Number: LP5907
  • Supplier Device Package: 4-X2SON (1x1)
  • Mounting Type: Surface Mount
  • Voltage - Output (Min/Fixed): 1.9V
  • Number of Regulators: 1
  • PSRR: 90dB ~ 60dB (100Hz ~ 100kHz)
  • Output Type: Fixed
  • Package / Case: 4-XDFN Exposed Pad
  • Packaging: Cut Tape (CT)
  • Protection Features: Over Temperature, Short Circuit
  • Control Features: Enable
  • Part Status: Active
  • Current - Output: 250mA
  • detail: Linear Voltage Regulator IC 1 Output 250mA 4-X2SON (1x1)
