TPS62000QDGSRQ1 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS62000QDGSRQ1	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Texas Instruments TPS62000QDGSRQ1
Output Type: Adjustable
Input Voltage: 2.5V~5.5V
Output Voltage: 0.8V~5.5V
Number of Outputs: 1
Switching Frequency: 750kHz
Output Current (Max): 600mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-10
Manufacturer: Texas Instruments
Voltage - Input (Max): 5.5V
Frequency - Switching: 750kHz
Packaging: Digi-Reel®
Series: Automotive, AEC-Q100
Output Configuration: Positive
Base Part Number: TPS620
Supplier Device Package: 10-VSSOP
Mounting Type: Surface Mount
Voltage - Output (Max): 5.5V
Synchronous Rectifier: Yes
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Voltage - Output (Min/Fixed): 0.8V
Voltage - Input (Min): 2.5V
Part Status: Active
Current - Output: 600mA
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 600mA 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
