REG104 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
REG104
|
|
حجم فایل
|
781.663
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
23
|
مشخصات فنی
-
Voltage - Input (Max):
15V
-
Packaging:
Cut Tape (CT)
-
Series:
-
-
Current - Quiescent (Iq):
0.7mA
-
Current - Supply (Max):
1.8mA
-
Voltage - Output (Min/Fixed):
3.3V
-
Number of Regulators:
1
-
PSRR:
65dB (120Hz)
-
Supplier Device Package:
DDPAK/TO-263-5
-
Package / Case:
TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
-
Control Features:
Enable
-
Part Status:
Obsolete
-
Base Part Number:
REG104
-
Voltage Dropout (Max):
0.48V @ 1A
-
Operating Temperature:
-40°C ~ 85°C
-
Current - Output:
1A
-
Output Configuration:
Positive
-
Manufacturer:
Texas Instruments
-
Mounting Type:
Surface Mount
-
Voltage - Output (Max):
-
-
Output Type:
Fixed
-
Protection Features:
Over Current, Over Temperature
-
detail:
Linear Voltage Regulator IC 1 Output 1A DDPAK/TO-263-5
