دیتاشیت TPS62360YZHT
مشخصات دیتاشیت
| نام دیتاشیت |
TPS62360YZHT
|
| حجم فایل |
93.177
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
58
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments TPS62361BYZHR
-
Output Type:
Adjustable
-
Input Voltage:
2.5V~5.5V
-
Output Voltage:
0.5V~1.77V
-
Number of Outputs:
1
-
Switching Frequency:
2.5MHz
-
Output Current (Max):
2.5A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
DSBGA-16(2.24x2.16)
-
Manufacturer:
Texas Instruments
-
Voltage - Input (Max):
5.5V
-
Frequency - Switching:
2.5MHz
-
Packaging:
Cut Tape (CT)
-
Series:
DCS-Control™
-
Output Configuration:
Positive
-
Base Part Number:
TPS623
-
Supplier Device Package:
16-DSBGA (2.24x2.16)
-
Mounting Type:
Surface Mount
-
Voltage - Output (Max):
1.77V
-
Synchronous Rectifier:
Yes
-
Package / Case:
16-UFBGA, DSBGA
-
Voltage - Output (Min/Fixed):
0.5V (0.96V, 1.16V, 1.4V)
-
Voltage - Input (Min):
2.5V
-
Part Status:
Active
-
Current - Output:
2.5A
-
detail:
Buck Switching Regulator IC Positive Adjustable (Programmable) 0.5V (0.96V, 1.16V, 1.4V) 1 Output 2.5A 16-UFBGA, DSBGA
