LMP7300MAX/NOPB دیتاشیت

LMP7300MAX/NOPB

مشخصات دیتاشیت

نام دیتاشیت LMP7300MAX/NOPB
حجم فایل 102.635 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

مشاهده دیتاشیت LMP7300MAX/NOPB

دانلود دیتاشیت

سایر مستندات

LMP7300 32 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LMP7300MAX/NOPB
  • Output Type: CMOS;开集;TTL
  • Supply Current: 13uA
  • Supply Voltage: 2.7V~12V;1.35V~6V
  • Number of Elements: 1
  • Operating Temperature: -40°C~+125°C
  • Propagation Delay Time: 15us
  • Input Bias Current (Ib): 0.003uA
  • Input Offset Voltage (Vos): 0.75mV
  • Input Hysteresis Voltage (Vhys): 1mV
  • Common Mode Rejection Ratio (CMRR): 100dB
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Base Part Number: LMP7300
  • Voltage - Input Offset (Max): 0.75mV @ 5V
  • CMRR, PSRR (Typ): 100dB CMRR, 100dB PSRR
  • Series: LMP®, PowerWise®
  • Supplier Device Package: 8-SOIC
  • Propagation Delay (Max): 15µs
  • Hysteresis: 1mV
  • Mounting Type: Surface Mount
  • Type: with Voltage Reference
  • Current - Output (Typ): -
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Part Status: Active
  • Packaging: Cut Tape (CT)
  • Current - Quiescent (Max): 13µA
  • Current - Input Bias (Max): 0.003µA @ 5V
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 12V, ±1.35V ~ 6V
  • detail: Comparator with Voltage Reference CMOS, Open-Collector, TTL 8-SOIC
