دیتاشیت LMS8117ADTX-ADJ/NOPB

LMS8117A

مشخصات دیتاشیت

نام دیتاشیت LMS8117A
حجم فایل 720.024 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LMS8117A

LMS8117A Datasheet

مشخصات

  • Voltage - Input (Max): 15V
  • Packaging: Cut Tape (CT)
  • Series: -
  • Current - Quiescent (Iq): 5mA
  • Current - Supply (Max): 10mA
  • Voltage - Output (Min/Fixed): 1.25V
  • Number of Regulators: 1
  • PSRR: 60 ~ 75 dB (120Hz)
  • Supplier Device Package: TO-252-3
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Control Features: -
  • Part Status: Active
  • Base Part Number: LMS8117
  • Voltage Dropout (Max): 1.25V @ 1A
  • Operating Temperature: 0°C ~ 125°C
  • Current - Output: 1A
  • Output Configuration: Positive
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Voltage - Output (Max): 13.8V
  • Output Type: Adjustable
  • Protection Features: Over Current, Over Temperature
  • detail: Linear Voltage Regulator IC 1 Output 1A TO-252-3
