دیتاشیت TPS715A01DRBT-NM
مشخصات دیتاشیت
| نام دیتاشیت | TPS715A Datasheet |
|---|---|
| حجم فایل | 2300.837 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت TPS715A Datasheet |
TPS715A Datasheet Datasheet |
|---|
مشخصات
- Voltage - Input (Max): 24V
- Packaging: Cut Tape (CT)
- Series: -
- Current - Quiescent (Iq): 4.2µA
- Current - Supply (Max): 5.8µA
- Voltage - Output (Min/Fixed): 1.2V
- Number of Regulators: 1
- PSRR: 60dB (100kHz)
- Supplier Device Package: 8-SON (3x3)
- Package / Case: 8-VDFN Exposed Pad
- Control Features: -
- Part Status: Active
- Base Part Number: TPS715
- Voltage Dropout (Max): 1.12V @ 80mA
- Operating Temperature: -40°C ~ 125°C
- Current - Output: 80mA
- Output Configuration: Positive
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Voltage - Output (Max): 15V
- Output Type: Adjustable
- Protection Features: Over Current, Reverse Polarity
- detail: Linear Voltage Regulator IC 1 Output 80mA 8-SON (3x3)
