ADS114S06, ADS114S08 Datasheet دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADS114S06, ADS114S08 Datasheet	دانلود دیتاشیت

RoHS: true
Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
Datasheet: Texas Instruments ADS114S08IPBSR
Interface: SPI
resolution: 16Bit
Supply Voltage: 2.7V~5.25V
number of channels: 12
sampling frequency: 4kHz
Operating Temperature: -50°C~+125°C
Package: TQFP-32(5x5)
Manufacturer: Texas Instruments
Base Part Number: ADS114S
Architecture: Sigma-Delta
Input Type: Differential, Pseudo-Differential, Single Ended
Number of Bits: 16
Series: -
Number of A/D Converters: 1
Number of Inputs: 12
Reference Type: External, Internal
Mounting Type: Surface Mount
Features: PGA, Temperature Sensor
Voltage - Supply, Analog: 2.7V ~ 5.25V
Supplier Device Package: 32-TQFP (5x5)
Package / Case: 32-TQFP
Data Interface: SPI
Packaging: Cut Tape (CT)
Sampling Rate (Per Second): 4k
Configuration: MUX-PGA-ADC
Voltage - Supply, Digital: 2.7V ~ 3.6V
Part Status: Active
detail: 16 Bit Analog to Digital Converter 12 Input 1 Sigma-Delta 32-TQFP (5x5)
