دیتاشیت LM629MX-8/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM628,629 Datasheet |
|---|---|
| حجم فایل | 1432.522 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت LM628,629 Datasheet |
LM628,629 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Type: 无刷直流BLDC
- Category: Power Supply Chip/Motor Driver ICs
- Datasheet: Texas Instruments LM629MX-8/NOPB
- Interface: Parallel
- Output Current: -
- Supply Voltage: 4.5V~5.5V
- Operating Temperature: -40°C~+85°C@(Ta)
- Package: SOP-24-300mil
- Manufacturer: Texas Instruments
- Step Resolution: -
- Voltage - Load: -
- Function: Controller - Commutation, Direction Management
- Output Configuration: Pre-Driver - Half Bridge (4)
- Current - Output: -
- Motor Type - AC, DC: Brushless DC (BLDC) Servo, Brushed DC Servo
- Base Part Number: LM629
- Technology: -
- Package / Case: 24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 24-SOIC
- Mounting Type: Surface Mount
- Part Status: Obsolete
- Motor Type - Stepper: -
- Series: -
- Applications: General Purpose
- Packaging: Tape & Reel (TR)
- Voltage - Supply: 4.5V ~ 5.5V
- detail: Motor Driver Parallel 24-SOIC
