- دیتاشیت UC3851N
UC3851N دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | UC3851N |
|---|---|
| حجم فایل | 101.164 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت UC3851N |
دانلود دیتاشیت |
|---|
سایر مستندات
UC1851, 2851, 3851 11 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Boost;Step-down;Flyback;Forward
- Datasheet: Texas Instruments UC3851N
- Duty Cycle: 50%
- Supply Voltage: 7.8V~32V
- Switching Frequency: 500kHz
- Operating Temperature: 0°C~+70°C@(Ta)
- Package: PDIP-18
- Manufacturer: Texas Instruments
- Base Part Number: UC385
- Mounting Type: Through Hole
- Series: -
- Internal Switch(s): No
- Supplier Device Package: 18-PDIP
- Voltage - Breakdown: -
- Voltage - Start Up: 8V
- Output Isolation: -
- Packaging: Tube
- Package / Case: 18-DIP (0.300", 7.62mm)
- Control Features: Frequency Control, Soft Start
- Voltage - Supply (Vcc/Vdd): 7.8V ~ 32V
- Frequency - Switching: Up to 500kHz
- Part Status: Active
- Fault Protection: Current Limiting, Over Voltage
- detail: Converter Offline Boost, Buck, Flyback, Forward Topology Up to 500kHz 18-PDIP
