دیتاشیت ADS6125IRHBT
مشخصات دیتاشیت
| نام دیتاشیت |
ADS6122-25
|
| حجم فایل |
3227.004
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
68
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Texas Instruments ADS6125IRHBT
-
Package:
QFN-32-EP(5x5)
-
Manufacturer:
Texas Instruments
-
Input Type:
Differential
-
Packaging:
Cut Tape (CT)
-
Series:
-
-
Number of A/D Converters:
1
-
Number of Inputs:
1
-
Features:
-
-
Ratio - S/H:ADC:
1:1
-
Supplier Device Package:
32-VQFN (5x5)
-
Data Interface:
LVDS - Parallel, Parallel
-
Package / Case:
32-VFQFN Exposed Pad
-
Sampling Rate (Per Second):
125M
-
Configuration:
S/H-ADC
-
Part Status:
Active
-
Base Part Number:
ADS6125
-
Architecture:
Pipelined
-
Operating Temperature:
-40°C ~ 85°C
-
Reference Type:
Internal
-
Mounting Type:
Surface Mount
-
Number of Bits:
12
-
Voltage - Supply, Analog:
3V ~ 3.6V
-
Voltage - Supply, Digital:
1.65V ~ 3.6V
-
detail:
12 Bit Analog to Digital Converter 1 Input 1 Pipelined 32-VQFN (5x5)
