TPS2044BDR دیتاشیت

TPS2044BDR

مشخصات دیتاشیت

نام دیتاشیت TPS2044BDR
حجم فایل 103.216 کیلوبایت
نوع فایل pdf
تعداد صفحات 66

دانلود دیتاشیت TPS2044BDR

دانلود دیتاشیت

سایر مستندات

TPS2041-44B/51-54B 65 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS2042BDRBT
  • Input Voltage: 2.7V~5.5V
  • Output Current: 500mA
  • Number of Outputs: 2
  • Resistor On-State: 70mΩ
  • Operating Temperature -: -40°C~+85°C
  • Package: SON-8-EP(3x3)
  • Manufacturer: Texas Instruments
  • Input Type: Non-Inverting
  • Fault Protection: Current Limiting (Fixed), Over Temperature, UVLO
  • Interface: On/Off
  • Features: Status Flag
  • Series: -
  • Current - Output (Max): 500mA
  • Package / Case: 8-VDFN Exposed Pad
  • Packaging: Cut Tape (CT)
  • Ratio - Input:Output: 1:2
  • Part Status: Active
  • Rds On (Typ): 70mOhm
  • Base Part Number: TPS204
  • Output Type: N-Channel
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Voltage - Load: 2.7V ~ 5.5V
  • Output Configuration: High Side
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-SON (3x3)
  • Switch Type: General Purpose
  • Voltage - Supply (Vcc/Vdd): Not Required
  • detail: Power Switch/Driver 1:2 N-Channel 500mA 8-SON (3x3)
