TLC3704, TLC3704Q دیتاشیت

TLC3704, TLC3704Q

مشخصات دیتاشیت

نام دیتاشیت TLC3704, TLC3704Q
حجم فایل 1463.317 کیلوبایت
نوع فایل pdf
تعداد صفحات 38

دانلود دیتاشیت TLC3704, TLC3704Q

دانلود دیتاشیت

سایر مستندات

TLC3704IPWR 38 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments TLC3704IDR
  • Output Type: CMOS;Push Pull;TTL
  • Supply Voltage: 3V~16V
  • Number of Elements: -
  • Operating Temperature: -40°C~+85°C
  • Input Bias Current (Ib): 5pA
  • Input Offset Voltage (Vos): 5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 84dB
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Base Part Number: TLC370
  • Voltage - Input Offset (Max): 5mV @ 10V
  • CMRR, PSRR (Typ): 84dB CMRR
  • Series: LinCMOS™
  • Supplier Device Package: 14-SOIC
  • Propagation Delay (Max): 4.5µs
  • Hysteresis: -
  • Mounting Type: Surface Mount
  • Type: General Purpose
  • Current - Output (Typ): 20mA
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Part Status: Active
  • Packaging: Cut Tape (CT)
  • Current - Quiescent (Max): 125µA
  • Current - Input Bias (Max): 5pA @ 5V
  • Voltage - Supply, Single/Dual (±): 3V ~ 16V
  • detail: Comparator General Purpose CMOS, Push-Pull, TTL 14-SOIC
