- دیتاشیت LM2650MX-ADJ/NOPB
دیتاشیت LM2650MX-ADJ/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2650 |
|---|---|
| حجم فایل | 977.67 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت LM2650 |
LM2650 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments LM2650MX-ADJ/NOPB
- Output Type: Adjustable
- Input Voltage: 4.5V~18V
- Output Voltage: 1.5V~16V
- Number of Outputs: 1
- Switching Frequency: 90kHz
- Output Current (Max): 3A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: SOP-24-300mil
- Manufacturer: Texas Instruments
- Package / Case: 24-SOIC (0.295", 7.50mm Width)
- Output Configuration: Positive
- Base Part Number: LM2650
- Packaging: Tape & Reel (TR)
- Frequency - Switching: 90kHz
- Supplier Device Package: 24-SOIC
- Part Status: Obsolete
- Current - Output: 3A
- Series: -
- Voltage - Input (Max): 18V
- Synchronous Rectifier: Yes
- Voltage - Output (Min/Fixed): 1.5V
- Voltage - Input (Min): 4.5V
- Mounting Type: Surface Mount
- Voltage - Output (Max): 16V
- detail: Buck Switching Regulator IC Positive Adjustable 1.5V 1 Output 3A 24-SOIC (0.295", 7.50mm Width)
