دیتاشیت TPS561201EVM-896
مشخصات دیتاشیت
| نام دیتاشیت | TPS561201EVM-896 User Guide |
|---|---|
| حجم فایل | 1109.591 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 17 |
دانلود دیتاشیت TPS561201EVM-896 User Guide |
TPS561201EVM-896 User Guide Datasheet |
|---|
مشخصات
- Regulator Topology: Buck
- Base Part Number: TPS561
- Outputs and Type: 1, Non-Isolated
- Series: D-CAP2™, SWIFT™
- Board Type: Fully Populated
- Manufacturer: Texas Instruments
- Utilized IC / Part: TPS561201
- Voltage - Input: 4.5V ~ 17V
- Main Purpose: DC/DC, Step Down
- Voltage - Output: 1.05V
- Supplied Contents: Board(s)
- Frequency - Switching: 580kHz
- Part Status: Active
- Current - Output: 1A
- detail: TPS561201 D-CAP2™, SWIFT™ DC/DC, Step Down 1, Non-Isolated Outputs Evaluation Board
