MCP3304-CI/SL 数据手册
其他文档
MCP3302, 04 Series 48 pages
技术规格
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Microchip Tech MCP3304-CI/SL
- Interface: SPI
- resolution: 13Bit
- Supply Voltage: 5V
- differential input: Yes
- number of channels: 4;8
- sampling frequency: 100kHz
- Operating Temperature: -40°C~+85°C
- Package: SOP-16
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 13
- Sampling Rate (Per Second): 100k
- Number of Inputs: 4, 8
- Input Type: Differential, Single Ended
- Data Interface: SPI
- Configuration: MUX-S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: External
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 5V
- Features: -
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
- Mounting Type: Surface Mount
- Base Part Number: MCP3304
- detail: 13 Bit Analog to Digital Converter 4, 8 Input 1 SAR 16-SOIC
