دیتاشیت MCP65R41T-1202E/CHY
مشخصات دیتاشیت
| نام دیتاشیت | MCP65R41,46 |
|---|---|
| حجم فایل | 575.902 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت MCP65R41,46 |
MCP65R41,46 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Microchip Tech MCP65R41T-1202E/CHY
- Output Type: CMOS;Push Pull;TTL
- Supply Current: 4uA
- Supply Voltage: 1.8V~5.5V
- Number of Elements: 1
- Operating Temperature: -40°C~+125°C
- Propagation Delay Time: 8us
- Input Bias Current (Ib): 1pA
- Input Offset Voltage (Vos): 10mV
- Input Hysteresis Voltage (Vhys): 5mV
- Common Mode Rejection Ratio (CMRR): 70dB
- Package: SOT-23-6
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: General Purpose
- Voltage - Supply, Single/Dual (±): 1.8V ~ 5.5V
- Voltage - Input Offset (Max): 10mV @ 5.5V
- Current - Input Bias (Max): 1pA @ 5.5V
- Current - Output (Typ): 50mA
- Current - Quiescent (Max): 4µA
- CMRR, PSRR (Typ): 70dB CMRR, 80dB PSRR
- Propagation Delay (Max): 8µs
- Hysteresis: 5mV
- Package / Case: SOT-23-6
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-23-6
- Base Part Number: MCP65R41
- detail: Comparator General Purpose CMOS, Push-Pull, TTL SOT-23-6
