MIC5211-LXYM6-TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MIC5211-LXYM6-TR
|
|
حجم فایل
|
79.432
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Microchip Tech MIC5211-LXYM6-TR
-
Output Current:
80mA
-
Output Voltage:
3.3V;5V
-
Dropout Voltage:
0.5V@(50mA)
-
Output Polarity:
positive
-
Number of Outputs:
2
-
Maximum Input Voltage:
16V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
450uA
-
Package:
SOT-23-6
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
2
-
Voltage - Input (Max):
16V
-
Voltage - Output (Min/Fixed):
3.3V, 5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.5V @ 50mA, 0.5V @ 50mA
-
Current - Output:
80mA, 80mA
-
Current - Quiescent (Iq):
450µA
-
Current - Supply (Max):
1.2mA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-6
-
Supplier Device Package:
SOT-23-6
-
Base Part Number:
MIC5211
-
detail:
Linear Voltage Regulator IC 2 Output 80mA, 80mA SOT-23-6
